48-10153
    Publish time 2023-06-30 11:18
Displacment(cc/rev): 15
48-10153

Vertical/Horizontal: Horizontal Displacment(cc/rev): 15;  VDC Power(v): 12&24 Driver Output(v): 24;   Refrigerant: R134a Speed range(rpm): 1200~4200 Rated speed(rpm): 3180 Rated current(A): 30 Rated motor input(W): 595 Rated capacity(W): 1910 Compressor height(Without assembly parts)(mm): 131 Compressor diameter (mm): Φ113.4 Accumulator diameter (mm): Φ31.8 Assembly radius a*b(mm): 160*145 Drive controller: Configurable
