48-10154
    Publish time 2023-06-30 11:18
Displacment(cc/rev): 16.3
48-10154

Vertical/Horizontal: Horizontal Displacment(cc/rev): 16.3; VDC Power(v): 12&24 Driver Output(v): 24;  Refrigerant: R134a Speed range(rpm): 1200~4200 Rated speed(rpm): 3180 Rated current(A): 32 Rated motor input(W): 644 Rated capacity(W): 2060 Compressor height(Without assembly parts)(mm): 131 Compressor diameter (mm): Φ113.4 Accumulator diameter (mm): Φ31.8 Assembly radius a*b(mm): 160*145 Drive controller: Configurable
