Applied Refrigerants: CFC, HCFC, HFC
Pressure: kg/cm, in.Hg, mmHg, bar, psi, kPa
Vacuum: kg/cm, in.Hg, mm Hg, bar, psl, kPa. Micron
Temperature: °C, °F
High Side: 0 psi to 725 psi (0 kPa to 5000 kPa)
Low Side: 0 psi to 435 psi (0 kPa to 3000 kPa)
Vacuum: 29.92 in.Hg to 0 in.Hg
Temperature: -40°F to 203°F (-40°C to 95°C)
High Side: 10875 psi (7500 kPa)
Low Side: 6255 psi (4500 kPa)
Vacuum: 59.84 in.Hg
Pressure High Side: ±2.175 psi (±15kPa)
Pressure Low Side: ±1.45 psi (±10kPa)
Vacuum: ±0.08859 in.Hg (±0.3kPa)
Temperature: ±0.5°C
Power Supply: 9V Battery for 30 hrs
LCD flashes to indicate low battery
Auto Shut-off Time: 30 min. Under no operation
(Extended 30 min by any button touch except On/Off Button)
Background Lamp Auto Shut-off Time: 10 min.
Operating Temperature: 10.4°F to 120.2°F (-12°C to 49°C)"
