Model No: 110-240V/50&60Hz Type: Full DC Inverter Current (Cooling/Heating): 8.7-14.0A/8.7-12.2A Net Weight (Rooftop): 44kg Gross Weight (Rooftop): 46kg Rated Cooling Capacity: 10000-15000 Btu Rated Heating Capacity: 12000-16000 Btu Power consumption (Cooling):1000-1650 EER/COP: 1.8-2.0/2.3-2.5 Controller: Remote Controller Air volume (high speed): 650 Noise Level (L/M/H), indoor: 56/59/62 dB(A) Noise Level (L/M/H), outdoor: 59/62/65 dB(A) Refrigerant (charge): R32 Compressor: GMCC Horizontal type Net Dimensions (Rooftop A/C): W769xH240×L1062(mm) Packing Dimensions(Rooftop A/C): W844×H338×L1137(mm) Net Weight (Indoor Panel) : 3.5kg Gross Weight (Indoor Panel) : 4.5kg Net Dimensions (Indoo r Panel): W515 xH65xL582(mm) Packing Dimensions(Indoor Panel): W575×H145×L647(mm) Ceiling opening dimensions: 400x400mm, or 362*362mm optional Ceiling thickness range: 26mm~~100mm, additional thicker available Ambient temperature range suggested from 18 ℃to 43 ℃ Indoor temperature set range from 18°Cto 30°C(from 64.4°Fto 86°F) Base chassis: High strength metal Main featurers: Full DC Inverter(100-240V); Low-profile; Remote Controller & Wi-Fi ; lonizer; 45℃ ambient temperature cooling; Certificate: CE, RoHS, SAA, CSA Loading quantity in 1X20GP/40GP/40HQ: 90/175/200 sets Functions: Remote Control & Bracket: Yes; Cooling function control: Yes; Heat pump function control: Yes; Fan function control: Yes; lonizer function control: Yes; Dry function control: Yes; Timer ON/OFFfunction control Yes;
